DJ-660

OIL-BASED HAZE MACHINE

DJ-660 is a cost-efficient and durable oil bases haze machine. Using high-pressure atomization technology, no heating system, to produce haze without waiting for pre-heat up. Extremely low fluid consumption rate and long-time continuous output, suit for all kinds of indoor and outdoor performances.

Features

  • User-friendly LCD display and operation;
  • Angle and speed adjustable fan using DC12V to ensure operation safety;
  • Professional anti-leaking tank prevents spill during transportation;
  • Quiet, Low noise and durable;
  • Dry and fine haze, diffuse fast;
  • No need heating, plug and play;
  • Built-in LCD control, wireless control and DMX control;
  • Please use DJPOWER professional oil base haze fluid PRO-H1L.

Specifications

AC Power

  • Input Voltage & Rate: 220-240 V, 50/60 Hz
  • Current Limiter Type: Fuse (F)
  • Current Limiter Specifications: 5 A, 250 V
  • Total Power Consumption: 500 W
  • Operating Current: 2.2 A
  • Power Input Connector: IEC

Heating

  • Heat Up Time: 0 min

Capacity

  • Fluid Tank Capacity : 2.5 L

Output

  • Max Output Volume: Appr. 3,000 cuft/min
  • Fluid Consumption @ full volume : Appr. 10 h/L
  • Maximum Continuous Duration @ full volume: Unlimited
  • Continuous Output : √
  • Max Continuous Output Level: 100%
  • Fully-loaded Cumulative Output Duration @ full volume: Appr. 3000 min

Features

  • Physical Thermostat: ×
  • Electronic Thermo-Control: √
  • Adjustable Output : ×
  • Adjustable Fan Speed: √
  • No-Fluid Protection: ×

Control

  • On-device Manual Control : LCD control board
  • Wireless Control: ×
  • Wired Control: ×
  • Control Protocol: DMX-512
  • DMX Channel Range: 2
  • Data Connectors: 3-pin XLR

Accessory

  • Flight Case: √
  • Power Cord: √
  • Wireless Controller Model: ×
  • Wired Controller Model: ×

Consumable

  • Consumable: PRO-H1L Oil Base Haze Fulid

Weight & Dimensions

  • Net Weight: 33.2 kg / 73.2 lb.
  • Gross Weight: 35.7 kg / 78.7 lb.
  • Machine Dimensions: 521 × 396 × 369 mm / 20.5 × 15.6 × 14.5 in.
  • Packing Dimensions: 590 × 450 × 460 mm / 23.2 × 17.7 × 18.1 in.
